2CG high temperature Gear Pump

Vacuum Pump
    Overview:
  • 2CG Series Hard-tooth Surface Residue Oil Pump could transport mostly all kinds of medium with bad lubrication and imperceptible grains, and the temperature below 200 C degree, the viscid dimension below 1500cst.
      • Application:
  • It can transport such medium as dreg oil, coal tar, falling oil, bubble stuff, additive and so on so forth. At the same time, it is the perfect transportation and pressure equipment for glass, bubble, building material, chemical industry, architecture, petroleum, eatable oil.
    • Model Flow Capacity Pressure Suction Vacuum Port Size Motor Power
    m3/h L/min Mpa m mm KW
    2CG-1 1 16.7 1.0/1.6 5 25 1.5
    2CG-1.5 1.5 25 1.0/1.6 5 25 1.5/2.2
    2CG-2 2 33.3 1.0/1.6 5 25 2.2/3
    2CG-3 3 50 1.0/1.6 5 25 3
    2CG-5 5 83.3 1.0/1.6 5 40 4
    2CG-6 6 100 1.0/1.6 5 40 4
    2CG-7.5 7.5 125 1.0/1.6 5 50 5.5
    2CG-10 10 167 1.0/1.6 5 50 5.5/7.5
    2CG-12 12 200 1.0/1.6 5 55 5.5/7.5
    2CG-15 15 250 1.0/1.6 5 55 7.5 /11
    2CG-18 18 300 1.0/1.6 5 55 7.5/11
    2CG-18 18 300 1 4.5 70 7.5
    2CG-29 29 483.3 1 4.5 70 11
    2CG-38 38 633 1 4 100 22
    2CG-58 58 960 1 3.5 100 30
    2CG-72 72 1200 0.6 4 150 37
    2CG-96 96 1600 0.6 4 150 45
